| Specification |
|
| System |
Avatar HD system |
| Power input |
9V-26V |
| Dimensions |
119.5*72*18.6mm |
| Weight |
145.9g(Antenna not included) |
| l/O Interface |
USB ,4Pin 1.0mm Port |
| Transmission Resolution |
1080p/100fps, 1080p/60fps, 720p/100fps,720p/60fps |
| Communication Frequency |
5.15GHz-5.30GHz;5.50GHz-5.85GHz; |
| Transmitter Power(EIRP) |
FCC:<30dBm; CE:<14dBm;
SRRC:<20dBm; MIC:<25dBm |
| 5.2G Antenna |
Frequency range:5.15GHz-5.30GHz;
Gain:7dBi(AVG)
Polarization:LHCP
|
| 5.8G Antenna |
Frequency range: 5.50GHz-6.00GHz
Gain:7dBi(AVG)
Polarization:LHCP
|
